Mittler Bros Machine & Tool 50297 User Manual
Instructions, Deluxe aircraft scales, Center of gravity instructions

For Further Technical Assistance Please Contact
Tanner Racing Products by MB
10 Cooperative Way Wright City, MO 63390
P.O. Box 110 Foristell, MO 63348
1-800-467-2464 Fax 1-636-745-2874
www.tannerracing.com
www.mittlerbros.com
Deluxe Aircraft Scales
Instructions
Racing Products
By
15” Pads
3 SCALE PAD OPERATION:
The LF display is defaulted to always read zero.
The RF scale/display should be the nose wheel or tail wheel.
4 & 3 SCALE PAD OPERATION:
4 scale pad/display is same as race car use.
3 scale pad/display: Requires LF scale pad connected to wire
cable, but not used to weight the aircraft.
The LF display will read zero.
1. Replace shocks with solid struts.
2. Fill airplane with all fluids.
3. To activate the CG mode press the up or down arrow and select Center Of
Gravity.
4. To adjust wheel base go into the CG menu and change the value to the
nearest inch using the up or down arrows.
5. Place airplane on scales.
6. Select “store weight”, this will store total airplane and front weights. If the CG
displays OVER, then the CG calculation has gone over 100 inches. You will
then need to try again.
7. Raise the rear of the airplane 10 inches.
8. CG number will appear on the screen.
9. To turn off the CG mode go back to the CG menu and turnoff the CG function.
Center of Gravity Instructions
