Edsal 1UGK7 - Manual (Page 3)

Flat Wire Deck
Step 4 Step 4 Step 4
Install the remaining 33” long,
1 Rivet Beams at the recommended
hole spacing between beams.
As before, insert the rivets on the
Beams into the slots on the Posts
and tap them down until they are
fully seated.
Step 5 Step 5 Step 5
Beginning with the bottom level, install the Wire
Decking and Bins. The Wire Decks are formed
to fit either 3 large, 4 medium, or 5 small bins.
Install the large bins on the bottom and small
bins on the top as illustrated. Place the wire
deck on the beams and set the bins on the deck.
Start at the bottom level and work your way up.
The flat wire deck is placed on the top level and
can be used as a shelf.
33” long,
1 Rivet Beams
2 Holes
2 Holes
2 Holes
4 Holes
4 Holes
4 Holes
4 Holes
4 Holes
4 Holes
Begin with the bottom level and the large bins,
then work upward
Small Bins
3 levels of 5 bins
Medium Bins
3 levels of 4 bins
Large Bins
3 levels of 3 bins
