Edsal Muscle Rack 7200 - Manual

Use Caution when handling and assembling metal parts. The metal may have sharp edges or corners. The use of pro-
tective gloves is recommended. Do not use this unit for anything that is outside the designed function of storage. Do
not store loose or heavy items on the top shelves or on the top of the unit, for they create a falling hazard that can injure
yourself or others. Always remember to use proper lifting techniques when moving either the boxed or assembled unit.
Part List & Product Specification : Muscle Rack 7200 & 7800 Series Storage Cabinets (patent pending) Part List & Product Specification : Muscle Rack 7200 & 7800 Series Storage Cabinets (patent pending) Part List & Product Specification : Muscle Rack 7200 & 7800 Series Storage Cabinets (patent pending)
Safety Instructions Safety Instructions Safety Instructions
It is recommended that the cabinets are assembled by more than one person. Use of a raised flat surface during
assembly is highly recommended. During shipping and handling, some of the tabs that are used for assembly may
have closed together. Use a flat tipped screwdriver to either pry up or push from behind the tab to re-open. To as-
sure the squareness of the unit, do not fully tighten the nuts and screws used in the assembly until all are in place.
After all nuts and screws are in place, square the unit and tighten all nuts and screws appropriately. Make sure that
the unit is placed on a level surface, as this may effect the performance of the unit.
General instructions General instructions General instructions
Should you have any comments, damage, missing parts, or problems with assembly of this unit please feel free to contact
our Muscle Rack manufacturing facility at, (773) 475-3000 and request customer service. We can also be reached on the
internet at the following email address : [email protected].
To obtain replacement parts, please provide the following information :
- Model # - Part # & Description - Location Purchased - Date Purchased
Reference Reference Reference
A
B
C
D
E
F
G
H
I
J
K
L
M
N
Congratulations ! On the purchase of your Muscle Rack
Storage Cabinet.
(some assembly required)
Page 1
(A) Right Hand Back
(B) Left Hand Back
(F) Bottom
(E) Top
(G) Shelves
Right Hand Back
Left Hand Back
Right Hand Side
Left Hand Side
Top
Bottom
Shelves
Shelf Clips
Right Hand Door
Left Hand Door
Door Rods
Screws (unslotted)
Nuts
Handle
1
1
1
1
1
1
4
8
1
1
2
12
12
1
Description Description Description
CCBK7218R
CCBK7218L
CCSD7122R
CCSD7122L
CCTO4123
CCBO3624
CCSH3719
7000CLP
CCDO6718R
CCDO6718L
CCDR3200
F102438S
F1024N
201L
CB721836GY CB721836GY CB721836GY — — — 4 Shelf 4 Shelf 4 Shelf – – – 72”h x 18”d x 36”w 72”h x 18”d x 36”w 72”h x 18”d x 36”w
1
1
1
1
1
1
4
8
1
1
2
12
12
1
CCBK7821R
CCBK7821L
CCSD7722R
CCSD7722L
CCTO4623
CCBO4124
CCSH4219
7000CLP
CCDO7320R
CCDO7320L
CCDR3500
F102438S
F1024N
201L
CB781841GY CB781841GY CB781841GY — — — 4 Shelf 4 Shelf 4 Shelf – – – 78”h x 18”d x 41”w 78”h x 18”d x 41”w 78”h x 18”d x 41”w
Required Tools Required Tools Required Tools
- 3/8” Socket or Nut Driver
- Small Blade Screwdriver
- Tipped Screwdriver (hole & tab
opening assistance)
(C) Right Hand Side
(D) Left Hand Side
(I) Right Hand Door
(J) Left Hand Door
(K) Door Rods
(H) Shelf Clips
(L) Screws
(M) Nuts
(N) Handle
