An ASSA ABLOY Group company 56
ASSA Rim Cylinders
TWIN V-10, TWIN EXCLUSIVE, TWIN PRO, TWIN MAXIMUM, CLIQ
Rim Component Parts
Rim Cylinder Parts
Model No. Description Price
Twin V-10
354947 SARGENT Drilled Rim Shell* 76.50
867429 1-1/8" Cylinder Shell* 48.50
807987 Corbin Jumbo 1-1/8" Shell* 58.50
353970 1-1/8" Cylinder Plug* 21.50
Twin Exclusive
354947 SARGENT Drilled Rim Shell* 76.50
867429 1-1/8" Cylinder Shell* 48.50
807987 Corbin Jumbo 1-1/8" Shell* 58.50
367019 1-1/8" Cylinder Plug* 21.50
Twin Pro/Twin Maximum
354947 SARGENT Drilled Rim Shell* 76.50
867429 1-1/8" Cylinder Shell* 48.50
807987 Corbin Jumbo 1-1/8" Shell* 58.50
356955 1-1/8" Cylinder Plug*† 21.50
* – Indicates Finished Components.
† – Specify Profile 0P4 for Twin Pro or 0M7 for Twin Maximum.
Cylinder Shell Cylinder Plug
