An ASSA ABLOY Group company 121
ASSA Profile Cylinders
TWIN V-10, TWIN EXCLUSIVE, TWIN PRO, TWIN MAXIMUM, CLIQ
Profile Cylinders
ASSA manufactures a wide variety of high security European style profile
cylinders including the Scandinavian oval cylinder used in ASSA modular
locksets, the Euro Din cylinder, and the British Oval cylinder.
Available for different door thicknesses and featuring
an adjustable cam actuator, ASSA profile cylinders can
be used with many types of imported
lockset and specialty hardware.
All profile cylinders are protected
with ASSA’s patented key control and
can be keyed into any new or existing
ASSA key system.
Benefits:
• Retrofits wide variety of European applications
• Adjustable cam actuator
• Two independent locking mechanisms to ensure security and optimum pick resistance
• Inactive "false" grooves on side pins designed to catch picking tools
• Patented key control
Warranty:
• ASSA guarantees its products against defective workmanship or wear resulting from defects for life
Certification:
• All ASSA Profile Cylinders are U.L. 437 listed
Technical Information:
• Euro Din and British Oval available for 3 different door thicknesses
• Cylinder housing and plug made of high quality brass
• Stainless steel top pins
• Bottom pins and master pins are nickel silver
Finishes:
BHMA Symbol U.S. Symbol Euro Finishes Description
625 US 26 11 Bright Chrome
626 US 26D 13 Satin Chrome
605 US 3 20 Bright Brass
606 US 4 23 Satin Brass
612 US 10 33 Satin Bronze
624 US 10B 46 Dark Oxidized Bronze
