An ASSA ABLOY Group company
32
ASSA Mortise Cylinders
TWIN V-10, TWIN EXCLUSIVE, TWIN PRO, TWIN MAXIMUM, CLIQ
Mortise Cylinders
BL
HT
BD
HD
1-7/8" Mortise Cylinder
Available Cams
Model/Cam#
Description
HD
HT
BL
BD
R-A
R-B
Comp
Sub
SNS
Twin V-10
V6557-1
with Adams Rite Cam
164.50 157.00 150.00
V6557-2
with Sargent Cam
164.50 157.00 150.00
V6557-3
with Cor. Clover Leaf Cam
164.50 157.00 150.00
V6557-4
with Cor. Beaver Tail Cam
164.50 157.00 150.00
V6557-5
with Yale Standard Cam
164.50 157.00 150.00
V6557-6
with Schlage “L” Cam
164.50 157.00 150.00
V6557-7
with Segal Type Cam
164.50 157.00 150.00
V6557-8
with Corbin Jumbo Cam
164.50 157.00 150.00
V6557-9
with Best 30H Cam
164.50 157.00 150.00
V6557-10
with Norment/AirTeq Cam
164.50 157.00 150.00
V6557-11
with Mogul Cam
164.50 157.00 150.00
V6557-12
with Cor. Jumbo Clover Leaf
164.50 157.00 150.00
V6557-13
with Sargent Short Cam
164.50 157.00 150.00
V6557-15
with Yale Rep. Cam
164.50 157.00 150.00
Twin Exclusive
E6557-1
with Adams Rite Cam
164.50 157.00 150.00
E6557-2
with Sargent Cam
164.50 157.00 150.00
E6557-3
with Cor. Clover Leaf Cam
164.50 157.00 150.00
E6557-4
with Cor. Beaver Tail Cam
164.50 157.00 150.00
E6557-5
with Yale Standard Cam
164.50 157.00 150.00
E6557-6
with Schlage “L” Cam
164.50 157.00 150.00
E6557-7
with Segal Type Cam
164.50 157.00 150.00
E6557-8
with Corbin Jumbo Cam
164.50 157.00 150.00
E6557-9
with Best 30H Cam
164.50 157.00 150.00
E6557-10
with Norment/AirTeq Cam
164.50 157.00 150.00
E6557-11
with Mogul Cam
164.50 157.00 150.00
E6557-12
with Cor. Jumbo Clover Leaf
164.50 157.00 150.00
E6557-13
with Sargent Short Cam
164.50 157.00 150.00
E6557-15
with Yale Rep. Cam
164.50 157.00 150.00
Twin 6000 Classic
6557-1
with Adams Rite Cam
168.00 159.00 150.00
6557-2
with Sargent Cam
168.00 159.00 150.00
6557-3
with Cor. Clover Leaf Cam
168.00 159.00 150.00
6557-4
with Cor. Beaver Tail Cam
168.00 159.00 150.00
6557-5
with Yale Standard Cam
168.00 159.00 150.00
6557-6
with Schlage “L” Cam
168.00 159.00 150.00
6557-7
with Segal Type Cam
168.00 159.00 150.00
6557-8
with Corbin Jumbo Cam
168.00 159.00 150.00
6557-9
with Best 30H Cam
168.00 159.00 150.00
6557-10
with Norment/AirTeq Cam
168.00 159.00 150.00
6557-11
with Mogul Cam
168.00 159.00 150.00
6557-12
with Cor. Jumbo Clover Leaf
168.00 159.00 150.00
6557-13
with Sargent Short Cam
168.00 159.00 150.00
6557-15
with Yale Rep. Cam
168.00 159.00 150.00
#11
#12
#13
#15
#1
#2
#3
#4
#5
#6
#7
#8
#9
#10
Mortise Cylinder Key:
HD – Head Diameter
HT – Head Thickness
BL – Body Length
(Includes Cam)
BD – Body Diameter
Cam Key:
R-A – Head Radius • R-B – Overall Radius
1.366
0.138
1.875
1.157
0.118
0.555
1.366
0.138
1.875
1.157
N/A
0.709
1.366
0.138
1.875
1.157
0.114
0.602
1.366
0.138
1.875
1.157
N/A
0.732
1.366
0.138
1.875
1.157
N/A
0.709
1.366
0.138
1.875
1.157
0.124
0.516
1.366
0.138
1.875
1.157
N/A
0.779
1.366
0.138
1.875
1.157
N/A
0.914
1.366
0.138
1.875
1.157
0.114
0.602
1.366
0.138
1.875
1.157
N/A
0.787
1.366
0.138
1.875
1.157
N/A
1.165
1.366
0.138
1.875
1.157
0.114
0.828
1.366
0.138
1.875
1.157
N/A
0.515
1.366
0.138
1.875
1.157
0.742
0.308
1.366
0.138
1.875
1.157
0.118
0.555
1.366
0.138
1.875
1.157
N/A
0.709
1.366
0.138
1.875
1.157
0.114
0.602
1.366
0.138
1.875
1.157
N/A
0.732
1.366
0.138
1.875
1.157
N/A
0.709
1.366
0.138
1.875
1.157
0.124
0.516
1.366
0.138
1.875
1.157
N/A
0.779
1.366
0.138
1.875
1.157
N/A
0.914
1.366
0.138
1.875
1.157
0.114
0.602
1.366
0.138
1.875
1.157
N/A
0.787
1.366
0.138
1.875
1.157
N/A
1.165
1.366
0.138
1.875
1.157
0.114
0.828
1.366
0.138
1.875
1.157
N/A
0.515
1.366
0.138
1.875
1.157
0.742
0.308
1.366
0.138
1.875
1.157
0.118
0.555
1.366
0.138
1.875
1.157
N/A
0.709
1.366
0.138
1.875
1.157
0.114
0.602
1.366
0.138
1.875
1.157
N/A
0.732
1.366
0.138
1.875
1.157
N/A
0.709
1.366
0.138
1.875
1.157
0.124
0.516
1.366
0.138
1.875
1.157
N/A
0.779
1.366
0.138
1.875
1.157
N/A
0.914
1.366
0.138
1.875
1.157
0.114
0.602
1.366
0.138
1.875
1.157
N/A
0.787
1.366
0.138
1.875
1.157
N/A
1.165
1.366
0.138
1.875
1.157
0.114
0.828
1.366
0.138
1.875
1.157
N/A
0.515
1.366
0.138
1.875
1.157
0.742
0.308
