An ASSA ABLOY Group company
47
ASSA Mogul Cylinders
TWIN V-10, TWIN EXCLUSIVE, TWIN PRO, TWIN MAXIMUM, CLIQ
1-1/8" IC Cylinder
1-1/2" IC Cylinder
High Security IC Mogul Cylinders
ASSA 1-1/2" R.R. Brink Interchangeable Core Mogul Cylinder
Model/Cam#
Description
HD
HT
BL
BD
R-A
R-B
Comp
Sub
SNS
Twin V-10
V8551BRIC
1-1/2" Mogul IC Cylinder
204.50 199.00 192.00
Twin Exclusive
E8551BRIC
1-1/2" Mogul IC Cylinder
204.50 199.00 192.00
Twin 6000 Classic
8551BRIC
1-1/2" Mogul IC Cylinder
220.50 211.50 202.50
2.245
0.120
1.590
2.000
N/A
N/A
2.245
0.120
1.590
2.000
N/A
N/A
2.245
0.120
1.590
2.000
N/A
N/A
ASSA 1-1/2" ADTECH Interchangeable Core Mogul Cylinder
Model/Cam#
Description
HD
HT
BL
BD
R-A
R-B
Comp
Sub
SNS
Twin V-10
V8551ADIC
1-1/2" Mogul IC Cylinder
204.50 199.00 192.00
Twin Exclusive
E8551ADIC
1-1/2" Mogul IC Cylinder
204.50 199.00 192.00
Twin 6000 Classic
8551ADIC
1-1/2" Mogul IC Cylinder
220.50 211.50 202.50
2.245
0.120
1.590
2.000
N/A
N/A
2.245
0.120
1.590
2.000
N/A
N/A
2.245
0.120
1.590
2.000
N/A
N/A
ASSA 1-1/2" Temporary Interchangeable Construction Core Mogul Cylinder
Model #
Description
HD
HT
BL
BD
R-A
R-B
Comp
Sub
SNS
8551SSICR
1-1/2" Mogul IC Cylinder
206.50
—
—
8551FAICR
1-1/2" Mogul IC Cylinder
206.50
—
—
8551NAICR
1-1/2" Mogul IC Cylinder
206.50
—
—
8551BRICR
1-1/2" Mogul IC Cylinder
206.50
—
—
8551ADICR
1-1/2" Mogul IC Cylinder
206.50
—
—
2.245
0.120
1.590
2.000
N/A
N/A
2.245
0.120
1.590
2.000
N/A
N/A
2.245
0.120
1.590
2.000
N/A
N/A
2.245
0.120
1.590
2.000
N/A
N/A
2.245
0.120
1.590
2.000
N/A
N/A
BL
HT
BD
HD
Mortise Cylinder Key:
HD – Head Diameter
HT – Head Thickness
BL – Body Length
(Includes Cam)
BD – Body Diameter
For temporary cores refer to Red Core on page 4.
