An ASSA ABLOY Group company 111
ASSA Auxiliary Locks
TWIN V-10, TWIN EXCLUSIVE, TWIN PRO, TWIN MAXIMUM, CLIQ
All measurements are in millimeters, to convert to inches multiply millimeters x .039370.
Auxiliary Locks
Ш30 Ш22
15 °
7
77
Ш22
18
48
24
18
Ш22 1
58
34
Ш4.5(4x)
48
24
Ш22
18 1.5
58
34
Ш4(4x)
18
Ш22 2
Ш34
18
Ш22 .75
Ш34
48
24
18
Ш22 2
58
34
18
Ш22
2
58
Ш11
Ш16
±
0.2
8
0.5
15 °
Ш11
Ш16
±
0.2
8
0.5
15 °
18
Ш22
1
Ш34
3
M11x1
NV 15
4.5
M11x1
NV 15
6.5
3.5
NV 26
M 22x1
Ø26
6
M22x1
Cylinder Ring 490271
Front Plate 490821 Front Plate 491450
Lock Washer 490246
Nail Plate 491299
Nut
490583 Housing Nut 490610
Housing Washer 490663
Nut
491439
Dust Cap 391053
Fixing Plate 490825 Fixing Plate 491449
Front Plate 497008
Front Plate 490657
Cam Lock Accessories
Cam Lock Accessories
Model No. Description Price
490271 Cam Lock cylinder ring 6.00
391053 Cam Lock dust cap 2.50
490825 Cam Lock fixing plate 2.00
491449 Cam Lock fixing plate 2.00
497008 Cam Lock front plate 3.50
490657 Cam Lock front plate 3.50
490821 Cam Lock front plate 3.50
491450 Cam Lock front plate 3.50
490246 Cam Lock washer .75
491299 Cam Lock nail plate 1.00
490583 Cam Lock nut 1.50
491439 Cam Lock nut (m11x1) 1.50
490610 Cam Lock housing nut (m22x1) 2.00
490663 Cam Lock housing washer 4.00
