Page 36: Assa mortise cylinders
An ASSA ABLOY Group company
35
BL
HT
BD
HD
Available Cams
#11
#12
#13
#15
#1
#2
#3
#4
#5
#6
#7
#8
#9
#10
Mortise Cylinder Key:
HD – Head Diameter
HT – Head Thickness
BL – Body Length
(Includes Cam)
BD – Body Diameter
Cam Key:
R-A – Head Radius • R-B – Overall Radius
Mortise Cylinders
ASSA Mortise Cylinders
TWIN V-10, TWIN EXCLUSIVE, TWIN PRO, TWIN MAXIMUM, CLIQ
2" Mortise Cylinder
Model/Cam#
Description
HD
HT
BL
BD
R-A
R-B
Comp
Sub
SNS
Twin Pro
6158-1
with Adams Rite Cam
175.50 168.00 161.00
6158-2
with Sargent Cam
175.50 168.00 161.00
6158-3
with Cor. Clover Leaf Cam
175.50 168.00 161.00
6158-4
with Cor. Beaver Tail Cam
175.50 168.00 161.00
6158-5
with Yale Standard Cam
175.50 168.00 161.00
6158-6
with Schlage “L” Cam
175.50 168.00 161.00
6158-7
with Segal Type Cam
175.50 168.00 161.00
6158-8
with Corbin Jumbo Cam
175.50 168.00 161.00
6158-9
with Best 30H Cam
175.50 168.00 161.00
6158-10
with Norment/AirTeq Cam
175.50 168.00 161.00
6158-11
with Mogul Cam
175.50 168.00 161.00
6158-12
with Cor. Jumbo Clover Leaf
175.50 168.00 161.00
6158-13
with Sargent Short Cam
175.50 168.00 161.00
6158-15
with Yale Rep. Cam
175.50 168.00 161.00
Twin Maximum
8858-1
with Adams Rite Cam
175.50 168.00 161.00
8858-2
with Sargent Cam
175.50 168.00 161.00
8858-3
with Cor. Clover Leaf Cam
175.50 168.00 161.00
8858-4
with Cor. Beaver Tail Cam
175.50 168.00 161.00
8858-5
with Yale Standard Cam
175.50 168.00 161.00
8858-6
with Schlage “L” Cam
175.50 168.00 161.00
8858-7
with Segal Type Cam
175.50 168.00 161.00
8858-8
with Corbin Jumbo Cam
175.50 168.00 161.00
8858-9
with Best 30H Cam
175.50 168.00 161.00
8858-10
with Norment/AirTeq Cam
175.50 168.00 161.00
8858-11
with Mogul Cam
175.50 168.00 161.00
8858-12
w/ Cor. Jumbo Clover Leaf
175.50 168.00 161.00
8858-13
with Sargent Short Cam
175.50 168.00 161.00
8858-15
with Yale Rep. Cam
175.50 168.00 161.00
Twin Low & Twin 600 Series Classic
Low
600
Description
HD
HT
BL
BD
R-A
R-B
COMP
SUB
—
L658-1
658-1
with Adams Rite Cam
163.00 154.00
—
L658-2
658-2
with Sargent Cam
163.00 154.00
—
L658-3
658-3
with Cor. Clover Leaf Cam
163.00 154.00
—
L658-4
658-4
with Cor. Beaver Tail Cam
163.00 154.00
—
L658-5
658-5
with Yale Standard Cam
163.00 154.00
—
L658-6
658-6
with Schlage “L” Cam
163.00 154.00
—
L658-7
658-7
with Segal Type Cam
163.00 154.00
—
L658-8
658-8
with Corbin Jumbo Cam
163.00 154.00
—
L658-9
658-9
with Best 30H Cam
163.00 154.00
—
L658-10
658-10 with Norment/AirTeq Cam
163.00 154.00
—
L658-11
658-11 with Mogul Cam
163.00 154.00
—
L658-12
658-12 w/ Cor. Jumbo Clover Leaf
163.00 154.00
—
L658-13
658-13 with Sargent Short Cam
163.00 154.00
—
L658-15
658-15 with Yale Rep. Cam
163.00 154.00
—
– Twin Maximum available with CLIQ™ Technology, add $500.00. Example: 8858-1 x CLIQ x 626 x Sidebar x Comp
1.366
0.138
2.00
1.157
0.118
0.555
1.366
0.138
2.00
1.157
N/A
0.709
1.366
0.138
2.00
1.157
0.114
0.602
1.366
0.138
2.00
1.157
N/A
0.732
1.366
0.138
2.00
1.157
N/A
0.709
1.366
0.138
2.00
1.157
0.124
0.516
1.366
0.138
2.00
1.157
N/A
0.779
1.366
0.138
2.00
1.157
N/A
0.914
1.366
0.138
2.00
1.157
0.114
0.602
1.366
0.138
2.00
1.157
N/A
0.787
1.366
0.138
2.00
1.157
N/A
1.165
1.366
0.138
2.00
1.157
0.114
0.828
1.366
0.138
2.00
1.157
N/A
0.515
1.366
0.138
2.00
1.157
0.742
0.308
1.366
0.138
2.00
1.157
0.118
0.555
1.366
0.138
2.00
1.157
N/A
0.709
1.366
0.138
2.00
1.157
0.114
0.602
1.366
0.138
2.00
1.157
N/A
0.732
1.366
0.138
2.00
1.157
N/A
0.709
1.366
0.138
2.00
1.157
0.124
0.516
1.366
0.138
2.00
1.157
N/A
0.779
1.366
0.138
2.00
1.157
N/A
0.914
1.366
0.138
2.00
1.157
0.114
0.602
1.366
0.138
2.00
1.157
N/A
0.787
1.366
0.138
2.00
1.157
N/A
1.165
1.366
0.138
2.00
1.157
0.114
0.828
1.366
0.138
2.00
1.157
N/A
0.515
1.366
0.138
2.00
1.157
0.742
0.308
1.366
0.138
2.00
1.157
0.118
0.555
1.366
0.138
2.00
1.157
N/A
0.709
1.366
0.138
2.00
1.157
0.114
0.602
1.366
0.138
2.00
1.157
N/A
0.732
1.366
0.138
2.00
1.157
N/A
0.709
1.366
0.138
2.00
1.157
0.124
0.516
1.366
0.138
2.00
1.157
N/A
0.779
1.366
0.138
2.00
1.157
N/A
0.914
1.366
0.138
2.00
1.157
0.114
0.602
1.366
0.138
2.00
1.157
N/A
0.787
1.366
0.138
2.00
1.157
N/A
1.165
1.366
0.138
2.00
1.157
0.114
0.828
1.366
0.138
2.00
1.157
N/A
0.515
1.366
0.138
2.00
1.157
0.742
0.308
