Component Parts Index
Model No. Description Page Number
868624 Rollpin - Corbin 134
868649 Russwin/Corbin std. & Heavy-Duty Cylinder Plug 83
868650 Russwin/Corbin 19F35 Cylinder Plug 83
868651 Corbin 25F26 Cylinder Plug 83
868652 Russwin/Corbin 25F65 Cylinder Plug 83
868654 Corbin New Style Standard-duty Tailpiece 134
868958 Schlage KIK Plug Cap 134
868959 Schlage KIK Plug Cap Spring 134
868960 Schlage KIK Plug Cap Pin 134
872610 #5 Yale/Standard Cam 134
872612 #15 Yale Replacement Cam 134
900250 Sargent 6-line, Arrow Tailpiece (short) 134
900251 Sargent 6-line, Arrow Tailpiece (long) 134
900252 Sargent 6-line, Arrow Tailpiece retaining ring 134
900253 Sargent/Arrow Tailpiece (Med.) 134
900254 Sargent 11-line T-Zone Tailpiece 134
900256 Yale Key-In-Lever Tailpiece 134
900257 Yale Key-In-Lever Roll Pin 134
907001 2-3/4" Faceplate Bolt 92
907002 2-3/4" Drive-In Bolt 92
907003 2-3/8" Faceplate Bolt 92
907004 2-3/8" Drive-In Bolt 92
907005 Strike Plate with Screws 92
907007 Reinforced Strike Box and Screws 92
907008 Security Bolt Guard Plate 92
907010 Deadbolt Mounting Bolts (Std. Single Cyl.) 92
907011 Deadbolt Mounting Bolts (Std. Double cyl.) 92
907012 Deadbolt mounting Bolts (3") 92
907013 Deadbolt Mounting Bolts (3-1/4") 92
907015 Security Balls for Single & Double Cylinder 92
907016 Deadbolt Strike Box Screw 92
907035 Mogul Chamber Screw Wrench 48
907035 Deadbolt Chamber Screw Wrench 92
907050 Corbin Jumbo Cylinder Thread Adapter 38
907203 Arrow Deadbolt/Weiser KIK Shell 83, 84
907306 #9 Best 30H Series 134
806266NT Cylinder Cap, No Thumbturn 92
867066/807261 Driver Pin 1-2 133
867067/807262 Driver Pin 3-4 133
867068/807263 Driver Pin 5-6 133
867069/807264 Driver Pin 7-8-9 133
92C-114 Arrow Deadbolt Cap 83, 84
92C-121 Arrow Deadbolt Washer 83, 84
92C-123 Arrow Deadbolt Blocking Piece 83, 84
92C-127 Arrow Deadbolt Plug Cap Spring 83, 84
92C-128 Arrow Deadbolt Plug Cap Pin 83, 84
CLK-1 Cam Lock Catch Kit (Includes 2 ea. of 31 Cam Catches) 110
CLP-D 7/8" Double D Cam Lock/Switch Lock Punch 110
An ASSA ABLOY Group company 158
ASSA Component Parts Index
TWIN V-10, TWIN EXCLUSIVE, TWIN PRO, TWIN MAXIMUM, CLIQ
