An ASSA ABLOY Group company 51
ASSA Rim Cylinders
TWIN V-10, TWIN EXCLUSIVE, TWIN PRO, TWIN MAXIMUM, CLIQ
Rim Cylinders Exploded View
Cylinder Springs
Top Pins
Cover Strip
Cylinder Housing
Cylinder Plug
Bottom Pins
Available Tailpieces
Sidebar Sidebar Springs Side Pins Side Pin Spring
Drill-resistant
Cylinder Housing Standard-pin
Tumbler System
Drill-resistant
Cylinder Plug
System Code
Large Key-bow
Side Bar Code
Coded Side Bar
Locking System
Rim Cylinder
Mounting Plate
Rim Cylinder
Mounting Screws
Tailpiece
Master Pins
