Page 35: 34 assa mortise cylinders
An ASSA ABLOY Group company
34
ASSA Mortise Cylinders
TWIN V-10, TWIN EXCLUSIVE, TWIN PRO, TWIN MAXIMUM, CLIQ
Mortise Cylinders
BL
HT
BD
HD
Available Cams
#11
#12
#13
#15
#1
#2
#3
#4
#5
#6
#7
#8
#9
#10
Mortise Cylinder Key:
HD – Head Diameter
HT – Head Thickness
BL – Body Length
(Includes Cam)
BD – Body Diameter
Cam Key:
R-A – Head Radius • R-B – Overall Radius
2" Mortise Cylinder
Model/Cam#
Description
HD
HT
BL
BD
R-A
R-B
Comp
Sub
SNS
Twin V-10
V6558-1
with Adams Rite Cam
175.50 168.00 161.00
V6558-2
with Sargent Cam
175.50 168.00 161.00
V6558-3
with Cor. Clover Leaf Cam
175.50 168.00 161.00
V6558-4
with Cor. Beaver Tail Cam
175.50 168.00 161.00
V6558-5
with Yale Standard Cam
175.50 168.00 161.00
V6558-6
with Schlage “L” Cam
175.50 168.00 161.00
V6558-7
with Segal Type Cam
175.50 168.00 161.00
V6558-8
with Corbin Jumbo Cam
175.50 168.00 161.00
V6558-9
with Best 30H Cam
175.50 168.00 161.00
V6558-10
with Norment/AirTeq Cam
175.50 168.00 161.00
V6558-11
with Mogul Cam
175.50 168.00 161.00
V6558-12
with Cor. Jumbo Clover Leaf
175.50 168.00 161.00
V6558-13
with Sargent Short Cam
175.50 168.00 161.00
V6558-15
with Yale Rep. Cam
175.50 168.00 161.00
Twin Exclusive
E6558-1
with Adams Rite Cam
175.50 168.00 161.00
E6558-2
with Sargent Cam
175.50 168.00 161.00
E6558-3
with Cor. Clover Leaf Cam
175.50 168.00 161.00
E6558-4
with Cor. Beaver Tail Cam
175.50 168.00 161.00
E6558-5
with Yale Standard Cam
175.50 168.00 161.00
E6558-6
with Schlage “L” Cam
175.50 168.00 161.00
E6558-7
with Segal Type Cam
175.50 168.00 161.00
E6558-8
with Corbin Jumbo Cam
175.50 168.00 161.00
E6558-9
with Best 30H Cam
175.50 168.00 161.00
E6558-10
with Norment/AirTeq Cam
175.50 168.00 161.00
E6558-11
with Mogul Cam
175.50 168.00 161.00
E6558-12
with Cor. Jumbo Clover Leaf
175.50 168.00 161.00
E6558-13
with Sargent Short Cam
175.50 168.00 161.00
E6558-15
with Yale Rep. Cam
175.50 168.00 161.00
Twin 6000 Classic
6558-1
with Adams Rite Cam
179.50 171.50 161.50
6558-2
with Sargent Cam
179.50 171.50 161.50
6558-3
with Cor. Clover Leaf Cam
179.50 171.50 161.50
6558-4
with Cor. Beaver Tail Cam
179.50 171.50 161.50
6558-5
with Yale Standard Cam
179.50 171.50 161.50
6558-6
with Schlage “L” Cam
179.50 171.50 161.50
6558-7
with Segal Type Cam
179.50 171.50 161.50
6558-8
with Corbin Jumbo Cam
179.50 171.50 161.50
6558-9
with Best 30H Cam
179.50 171.50 161.50
6558-10
with Norment/AirTeq Cam
179.50 171.50 161.50
6558-11
with Mogul Cam
179.50 171.50 161.50
6558-12
with Cor. Jumbo Clover Leaf
179.50 171.50 161.50
6558-13
with Sargent Short Cam
179.50 171.50 161.50
6558-15
with Yale Rep. Cam
179.50 171.50 161.50
1.366
0.138
2.00
1.157
0.118
0.555
1.366
0.138
2.00
1.157
N/A
0.709
1.366
0.138
2.00
1.157
0.114
0.602
1.366
0.138
2.00
1.157
N/A
0.732
1.366
0.138
2.00
1.157
N/A
0.709
1.366
0.138
2.00
1.157
0.124
0.516
1.366
0.138
2.00
1.157
N/A
0.779
1.366
0.138
2.00
1.157
N/A
0.914
1.366
0.138
2.00
1.157
0.114
0.602
1.366
0.138
2.00
1.157
N/A
0.787
1.366
0.138
2.00
1.157
N/A
1.165
1.366
0.138
2.00
1.157
0.114
0.828
1.366
0.138
2.00
1.157
N/A
0.515
1.366
0.138
2.00
1.157
0.742
0.308
1.366
0.138
2.00
1.157
0.118
0.555
1.366
0.138
2.00
1.157
N/A
0.709
1.366
0.138
2.00
1.157
0.114
0.602
1.366
0.138
2.00
1.157
N/A
0.732
1.366
0.138
2.00
1.157
N/A
0.709
1.366
0.138
2.00
1.157
0.124
0.516
1.366
0.138
2.00
1.157
N/A
0.779
1.366
0.138
2.00
1.157
N/A
0.914
1.366
0.138
2.00
1.157
0.114
0.602
1.366
0.138
2.00
1.157
N/A
0.787
1.366
0.138
2.00
1.157
N/A
1.165
1.366
0.138
2.00
1.157
0.114
0.828
1.366
0.138
2.00
1.157
N/A
0.515
1.366
0.138
2.00
1.157
0.742
0.308
1.366
0.138
2.00
1.157
0.118
0.555
1.366
0.138
2.00
1.157
N/A
0.709
1.366
0.138
2.00
1.157
0.114
0.602
1.366
0.138
2.00
1.157
N/A
0.732
1.366
0.138
2.00
1.157
N/A
0.709
1.366
0.138
2.00
1.157
0.124
0.516
1.366
0.138
2.00
1.157
N/A
0.779
1.366
0.138
2.00
1.157
N/A
0.914
1.366
0.138
2.00
1.157
0.114
0.602
1.366
0.138
2.00
1.157
N/A
0.787
1.366
0.138
2.00
1.157
N/A
1.165
1.366
0.138
2.00
1.157
0.114
0.828
1.366
0.138
2.00
1.157
N/A
0.515
1.366
0.138
2.00
1.157
0.742
0.308
