ASSA Profile Cylinders
TWIN V-10, TWIN EXCLUSIVE, TWIN PRO, TWIN MAXIMUM, CLIQ
Profile Cylinders Ordering Information
How To Order Profile Cylinders:
Specify Model No. Finish Form Door Thickness Cam Position Keyway
Example: ..........V6531 ..........605............Comp ....................61 ...............................1............................95-200
How To Determine Cam Position:
Twin Pro available through special order.
British Oval and Euro Din Cylinders are available in 626 and 605 finish only.
Contact
Customer
Service
Department
For Keyway
Numbers.
Catalog Page.
Model No. Finish Form Door Thickness Cam Position Keyway
V6531 605 COMP 61 1 95-200
