APPENDIX 1
BEARING ALIGNMENT COLLAR DETAIL
The bearing alignment collar is used to install the radial bearing on the 4MXR, 5MXR, and 6MXR bearing
configurations. It is recommended that you use this tool so as not to damage the radial bearing and or bearing
housing during rotating assembly installation.
Fig. 81
BEARING ALIGNMENT
COLLAR
8
