Goulds Pumps AF (Axial Flow) (6"-36) MXR Bearings" - Manual (Page 65)

AF (6-36) IOM 63
Parts List and Materials of
Construction
Item
Part Name
Standard Materials of
Construction
Cast Iro
n
304 316
Alloy 20
Duple
x
SS
904L
Monel
Inco
nel
Nickel
T
it
a
ni
um
100 Elbow 1002 1284 1245 1283 1247 1233 1119 1273 1601 1220
101 Impeller 1002 1284 1245 1283 1247 1233 1119 1273 1601 1220
105 Lantern ring Teflon
106 Packing Dependent on Pumpage
107 Gland 1002 1284 1245 1283 1247 1233 1119 1273 1601 1220
112C Outboard bearing Steel
113A Oil breather Steel
109
Thrust bearing
retainer
1000
122 Shaft 2206 2228 2229 2230 3279 2369 2150 2266 2155 2156
126 Shaft Sleeve 1002 1284 1245 1283 1247 1233 1119 1273 1601 1220
134 Bearing housing 1000
136 Bearing locknut Steel
142B Keyed washer Steel
168C Inboard bearing Steel
178 Impeller key 2213 2228 2229 2230 2248 2369 2150 2266 2155 2156
178D Sleeve key 2213 2228 2229 2230 2248 2369 2150 2266 2155 2156
179 Drip pan 316 standard. Other options available.
184 Stuffing box cover 1002 1284 1245 1283 1247 1233 1119 1273 1601 1220
198 Impeller screw 2210 2228 2229 2230 2248 2369 2150 2266 2155 2156
199 Impeller lockplate 3201 2228 3211 2230 3270 2369 2150 2266 2155 2156
220 Stuffing Box 1002 1284 1245 1283 1247 1233 1119 1273 1601 1220
222A Set screw, Sleeve 2213 2228 2229 2230 2248 2369 2150 2266 2155 2156
222B
Set screw, Oil
wheel
Steel
239B Frame foot, inboard Steel
239A
Frame foot,
outboard
Steel
248 Oil wheel Iron
251C Plug, Oiler Steel
315A Elbow w/ Casing 1002 1284 1245 1283 1247 1233 1119 1273 1601 1220
315B Liner, Elbow 1002 1284 1245 1283 1247 1233 1119 1273 1601 1220
332A
Laby seal,
outboard
Carbon Filled Teflon
332B Laby seal, inboard Carbon Filled Teflon
351 Gasket, Stuff. Box 5302 5303 5309
351A
Gasket,
Elbow/Casing
5302 5303 5309
353 Gland stud
2229
355 Gland nuts
357G Nuts, Casing 2210 2228 2229 2230 2248 2369 2150 2266 2155 2156
356A Adjusting bolts Steel
358U Oil fill plug Steel
360W Cover, Oil Cooling Steel
361 Gasket, Oil Cooling 5302
370F HHCS, Oil Cooling Steel
370G HHCS Casing 2210 2228 2229 2230 2248 2369 2150 2266 2155 2156
370J
HHCS Bearing
Housing / Elbow
2210 2228 2229 2230 2248 2369 2150 2266 2155 2156
370K HHCS Foot, Front Steel
370H
HHCS SB Cover-
Frame
Steel
370L
HHCS SB Cover-
Bearing Housing
Steel
Parts List and Materials of
Construction
Item
Part Name
Standard Materials of
Construction
Cast Iro
n
304 316
Alloy 20
Duple
x
SS
904L
Monel
Inco
nel
Nickel
T
it
a
ni
um
370M
HHCS Impeller
Cover
2210 2228 2229 2230 2248 2369 2150 2266 2155 2156
370Q Frame Foot, Rear Steel
370S End Cover Screws Steel
370U HHCS Adj. lug 2210 2228 2229 2230 2248 2369 2150 2266 2155 2156
370V HHCS Adj screw 2210 2228 2229 2230 2248 2369 2150 2266 2155 2156
370Y Frame foot screws Steel
382
Lock
washer
Steel
383 Mechanical Seal As specified
388Z Drip Pan Screws Stainless
400 Coupling Key Steel
408 Plug, Drain Steel
408A Sensor plugs Steel
408H Plug, Impeller 2210 2228 2229 2230 2248 2369 2150 2266 2155 2156
412F O-ring, Sleeve 5302 5303 5309
443X Spacer Steel
496
O-ring, Stuffing Box
Cover
5302 5303 5309
496A O-ring End Cover BUNA-N
496B
O-ring, Impeller
Cap
5302 5303 5309
496C
O-ring, Impeller
Nose
5302 5303 5309
540C
Gasket, Bearing
Housing
5302
555D Drip Pan Elbow Stainless Steel Standard. Other options available.
600Z
HHCS,
SBX/SBXCVR
2210 2228 2229 2230 2248 2369 2150 2266 2155 2156
787H Adjusting Bar Steel
9727 Male Connector Steel
9728 Female Connector Steel
9841 Cooling Coil 2229
9879
Adjusting Lug,
Casing
2210 2228 2229 2230 2248 2369 2150 2266 2155 2156
9985 Impeller Cover 2210 2228 2229 2230 2248 2369 2150 2266 2155 2156
