NOTE: The photo at the left show the table laying
top down on the carpeted floor and standing above
the table looking downward.
Slightly lift the table up and slide the side shelf (Part
H) underneath the drawer section, making sure to line
up the Side shelf so that the edges are flush and even
with the edge of the table top. See FIG 20
Continue with attachment of side shelf
on next page.
STEP 15] Attaching Side Shelf
Pg. 11
May 08- RPI
Manchester Split-top Table Assembly Instructions
WARNING:
To Install the SIDE SHELF, the Table must be turned back over onto its Table Top.
Use 2 People to turn Table over onto the Table Top, making sure it is placed on a
protected surface like a carpeted floor.
Drawer Bottom
Table Top
Drawer
Bottom
Table Top
Side Shelf
Line up the Side shelf so that
the edge of the shelf is flush
with the edge of the table top.
Indicated by the white line.
FIG 20
