Team Associated RC8.2e - Manual (Page 6)

6
:: Front/Rear Differential Assembly - Bag C & CC
:: Front/Rear Differential Assembly (cont.) - Bag C & CC
:: Front/Rear Differential Assembly (cont.) - Bag C & CC
Diff outdrive
differences
!
89120
Diff
washer
89121
Diff
O-Ring
89120
Diff
outdrive
pin
89120
Sun gear
89120
Spider
gear
assembly
25236
8x16mm
bearing
89477
Light
outdrives
(front, long)
89121
Diff
O-Ring
89478
Light
outdrives
(rear, short)
89115
Diff
housing
x2
Align pin with
groove in sun gear
!
#6588
black grease
#6588
black grease
Center Diff
Outdrive
Front Diff
Outdrive
(long)
Rear Diff
Outdrive
(short)
