Team Associated RC8.2e - Manual (Page 10)

:: Front Bulkhead Assembly (cont.) - Bag D & DD
:: Front Bulkhead Assembly (cont.) - Bag D & DD
:: Front Bulkhead Assembly (cont.) - Bag D & DD
10
25236
8x16mm
bearing
89474
3x22mm
shcs
89224
3x16mm
shcs
89454
3x12mm
shcs
25215
M3
locknut
89221
5x4mm
setscrew
89481
Low
B-Plate
89538
RC8.2 front
shock tower
(aluminum)
89472
Front
bulkhead
spacer
89017
Inner
gearbox
89114
Diff pinion
gear
89117
Diff
shim
89017
Outer
gearbox
x2
x2
x2
x2
x4
x4
Key setscrew onto
flat side of shaft.
Tighten with no
endplay.
!
#1596
thread lock
!
!
Diff shims
installed to diff,
diff installed to
gearbox.
!
Wrap boot over the O-Ring.
!
!
