Team Associated RC8.2e - Manual (Page 19)

19
:: Rear Suspension Assembly (cont.) - Bag G & GG
::: Rear Suspension Assembly (cont.) - Bag G & GG
::: Rear Suspension Assembly (cont.) - Bag G & GG
89452
3x50mm
shcs
89230
Silver cone
washer
25192
3x20mm
shcs
31531
3x6mm
bhcs
89487
RC8B rear
swaybar
(2.5 green)
89039
Hinge pin
bushings
89463
Aluminum
D-plate
25215
M3
locknut
25225
3x3mm
setscrew
89017
Swaybar
mount
89466
Inner hinge pin
(4mm HMA)
x2
x2
x2
x2
x2
x2
x2
x2
1 dot
hinge pin
bushing
2
1
1 4
2 5
3 6
3
#1596
thread lock
#1596
thread lock
2 dot down
hinge pin
bushing
89470
Hinge pin
bushings
(two dot)
x2
