DMX Repeater Pro User’s Guide
6
Selecting a Personality
To begin, press the Home button. The screen will read “Pathway
DMX Repeater Pro” and the OK button will light up green. Press the
up/down arrows to cycle through the following screens: “Discover
RDM Devices”, “DMX Monitor and Console”, “Status Information”
and “Repeater Configuration”.
When “Repeater Configuration” appears, press the check-mark to
select. Press the up/down arrows until this screen appears:
Press the check-mark to select, then the up/down arrows to choose
from “RDM Splitter”, “DMX Merger” and “DMX Hub”, which will
appear on the lower line. Use the check-mark to accept the
personality you require. Setting a basic personality will clear any
port-by-port customization.
Personality Descriptions
RDM Splitter: A one-in/eight-out opto-splitter with RDM functionality
enabled on all ports. This is the factory default personality.
RDM can be disabled on a port-by-port basis to accommodate some
older equipment that may misinterpret RDM requests as DMX level
changes. See “Port Customization Options”.
DMX Merger: A one-in/eight-out or two-in/seven out merger/opto-
splitter with RDM disabled on all ports.
While in this personality, the Repeater Pro scans ports A through H
for active DMX. If found, the second DMX source will be merged with
the primary “DMX IN” signal on a highest-takes-precedence basis.
Also see “More on DMX Merger Mode”.
RDM discovery and commands will not work on ports that are
merging DMX due to timing constraints in the RDM protocol.
DMX Hub: A nine-in/eight-out switcher. The DMX Repeater Pro
scans each port in turn (including the primary input port “DMX IN”)
until a DMX source is found. It then reconfigures all other ports
(except the primary input port) as outputs and routes the DMX signal
▲Personality ▲
▼RDM Splitter ▼
