DMX Repeater Pro User’s Guide
9
By using the left/right arrow keys, you can highlight a channel
and see the current numeric level on the right hand side of the
screen. The upper number is the DMX value between 0 and 255.
The lower number is the same value shown in hexadecimal
format. Levels can easily be compared against console or
controller sources.
The Console generates DMX levels, allowing an independent
check on downstream or end devices. Use the left/right arrows to
highlight the desired channel on the display and press the check
mark to select it. The level information on the right hand side will
blink. Use the up/down arrows to change the channel’s level.
Check to see if the end device is reacting accordingly.
Press the check mark again to release the channel and have it
return to its previous level. The DMX Repeater Pro will not
accidentally cause cueing changes with this feature.
For the Status Screens, use the following illustrations as
reference.
DMX Status:
Repeater mode: the number of source channels is shown.
DMX Merge: the number of source channels is shown for both
the primary “DMX IN” port and for the secondary source, in this
instance port B.
Hub mode: the active source port and number of channels is
shown. If the primary “DMX IN” port is active, the lower line will
read “A-H inactive”.
▲DMX Input ▲
▼512 Channels ▼
▲I 512 channels ▲
▼B 48 channels ▼
▲Input inactive ▲
▼A 512 channels ▼
