DMX Repeater Pro User’s Guide
4
unidirectional. The standard connector type is 5-pin XLR. Since
its inception in 1986, there have been two revisions: USITT
DMX512/1990 and the newer ANSI E1.11 DMX512-A (2005)
version. The DMX Repeater Pro is designed to work seamlessly
with these and all manufacturer-specific variants of the protocol.
RDM – A recent (2006) addition to the DMX512 protocol is ANSI
E1.20 RDM (Remote Device Management), a separate, optional
standard intended to enhance the value of DMX by adding
command/query-and-response functionality on top of the basic
DMX streaming-data structure. RDM is a duplex or bi-directional
protocol that requires DMX ports to transmit as well as receive.
Potential features include remote device addressing and status
reporting. The DMX Repeater Pro supports RDM on all ports.
S
TARTUP
D
ISPLAYS
Plug in the power cord to your DMX Repeater Pro. The internal
power supply will automatically sense and accommodate any
voltage/frequency from 100-240VAC and 50/60 Hz. The front
panel liquid-crystal display (LCD) and the keypad will illuminate.
Once boot up is completed, the display will cycle through the
three main status displays.
DMX Status: The first display shows DMX activity and gives the
number of input channels. Some devices transmit less than a full
universe of 512. If there is no DMX present, the display will read
‘DMX Input – Inactive’.
RDM Status: The second display shows RDM activity. In some
modes, the screen will read “RDM Disabled”.
Port Status: The last display shows the port-by-port
customization for handling DMX and RDM information.
For full explanations of the displays, see “Status and Monitoring”.
▲DMX Input ▲
▼512 Channels ▼
▲Port ABCDEFGH ▲
▼Src IIIIIIII ▼
▲RDM ▲
▼0 messages ▼
