Monitoring System Activity and Performance 152-388-100-02, Issue 2
28 June 6, 2000 H2TU-C-388 List 1
Performance History at the HDSL2 Interface
The HDSL2 interface has 31-day, 48-hour, 25-hour, and current statistic screens for the H2TU-C. Figure 17 and
Figure 18 below are examples of 31-day and 48-hour performance history screens. Figure 19 and Figure 20 on
page 29 are examples of 25-hour and current statistics performance history screens, respectively. Refer to
Table 10 on page 30 for descriptions of the kinds of errors reported on all HDSL2 performance screens.
Figure 17. H2TU-C HDSL2 31-Day Performance History
Figure 18. H2TU-C HDSL2 48-Hour Performance History
Monitor Performance Event Log Config Inventory Rlogon Help
H2TU-C HDSL2 31 Day History (Page 1 of 3)
------------------------------------------------------------------------------
Date ES SES UAS CV LOSWS
04/01 - - - - -
04/02 - - - - -
04/03 - - - - -
04/04 - - - - -
04/05 - - - - -
04/06 - - - - -
04/07 - - - - -
04/08 - - - - -
04/09 - - - - -
04/10 - - - - -
04/11 - - - - -
04/12 - - - - -
04/13 14 10 10 14 10
Press: (N)ext Page, (P)revious Page, C(l)ear History
------------------------------------------------------------------------------
Press to cycle through Interface : H2TU-C HDSL2
choices and to view Statistics : 31 Day History
ID: xxxx--xxxx--xxxx--xxxx 04/15/00 12:30:01 H2TU-C System: OK
Monitor Performance Event Log Config Inventory Rlogon Help
H2TU-C HDSL2 48 Hour History (Page 1 of 4)
------------------------------------------------------------------------------
Time ES SES UAS CV LOSWS
23:00 - - - - -
1:00 - - - - -
2:00 - - - - -
3:00 - - - - -
4:00 - - - - -
5:00 - - - - -
6:00 - - - - -
7:00 - - - - -
8:00 - - - - -
9:00 - - - - -
10:00 - - - - -
11:00 14 10 10 12 10
12:00 0 0 0 2 0
Press: (N)ext Page, (P)revious Page, C(l)ear History
------------------------------------------------------------------------------
Press to cycle through Interface : H2TU-C HDSL2
choices and to view Statistics : 48 Hour History
ID: xxxx--xxxx--xxxx--xxxx 04/15/00 12:30:01 H2TU-C System: OK
