Monitoring System Activity and Performance 152-388-100-02, Issue 2
26 June 6, 2000 H2TU-C-388 List 1
Examples of current statistics screens are shown below. Figure 15 and Figure 16 show statistics for the DS1
interface at the remote unit and line unit, respectively. These screens report 1-day, 1-hour, and 15-minute statistics.
Figure 15. H2TU-R DS1 Current Statistics
Figure 16. H2TU-C DS1 Current Statistics
Monitor Performance Event Log Config Inventory Rlogon Help
H2TU-R DS-1 Current Statistics
------------------------------------------------------------------------------
1 Day 1 Hour 15 Min
Start 00:00 12:00 12:30
CV-L 0 0 0
ES-L 0 0 0
SES-L 0 0 0
UAS-L 0 0 0
CV-P 0 0 0
ES-P 0 0 0
SES-P 0 0 0
UAS-P 0 0 0
PRM-NE 0 0 0
PRM-FE 0 0 0
B8ZSS 0 0 0
MSEC 3482 1801 1
Press: C(l)ear Current Statistics
------------------------------------------------------------------------------
Press to cycle through Interface : H2TU-R DS-1
choices and to view Statistics : Current
ID: xxxx--xxxx--xxxx--xxxx 04/15/00 12:30:01 H2TU-C System: OK
Monitor Performance Event Log Config Inventory Rlogon Help
H2TU-C DS-1 Current Statistics
------------------------------------------------------------------------------
1 Day 1 Hour 15 Min
Start 00:00 12:00 12:30
CV-L 0 0 0
ES-L 0 0 0
SES-L 0 0 0
UAS-L 0 0 0
CV-P 0 0 0
ES-P 0 0 0
SES-P 0 0 0
UAS-P 0 0 0
B8ZSS 0 0 0
MSEC 3482 1801 1
Press: C(l)ear Current Statistics
------------------------------------------------------------------------------
Press to cycle through Interface : H2TU-C DS-1
choices and to view Statistics : Current
ID: xxxx--xxxx--xxxx--xxxx 04/15/00 12:30:01 H2TU-C System: OK
