Monitoring System Activity and Performance 152-388-100-02, Issue 2
24 June 6, 2000 H2TU-C-388 List 1
U
SING THE
P
ERFORMANCE
S
CREENS TO
V
IEW
P
ERFORMANCE
D
ATA
The Performance screens display:
• CRC statistics for the HDSL2 or DS1 interface in 31-day, 48-hour, 25-hour, and current history reports
• Alarm statistics for the HDSL2 ( Figure 23 on page 33 ) or DS1 interfaces ( Figure 22 on page 31 ) on a
continuous basis
To access the Performance history screens:
1 Type to select the Performance screen.
2 Press the to select either interface (H2TU-C DS1, H2TU-R DS1, H2TU-C HDSL2 or H2TU-R
HDSL2), then press .
3 Press the to select the type of statistics (Current, Alarm History, 25 Hour History, 48 Hour
History, or 31 Day History), then press .
Performance History at the DS1 Interface
The Performance History for the DS1 Interface provides 31-day, 48-hour, 25-hour, and current statistics screens
for the H2TU-C and the H2TU-R (as viewed from the H2TU-C).
Figure 12 below and Figure 13 on page 25 are
examples of DS1 performance history screens at the remote unit. Figure 14 on page 25 is an example of DS1
performance history screens at the line unit. Refer to Table 9 on page 27 for descriptions of the kinds of errors
reported on DS1 interface screens.
Figure 12. H2TU-R DS1 31-Day Performance History
P
SPACEBAR
ENTER
SPACEBAR
ENTER
Monitor Performance Event Log Config Inventory Rlogon Help
H2TU-R DS-1 31 Day History (Page 1 of 3)
------------------------------------------------------------------------------
Date CV-L ES-L SES-L UAS-L CV-P ES-P SES-P UAS-P PRM-NE PRM-FE
04/01 - - - - - - - - - -
04/02 - - - - - - - - - -
04/03 - - - - - - - - - -
04/04 - - - - - - - - - -
04/05 - - - - - - - - - -
04/06 - - - - - - - - - -
04/07 - - - - - - - - - -
04/08 - - - - - - - - - -
04/09 - - - - - - - - - -
04/10 - - - - - - - - - -
04/11 - - - - - - - - - -
04/12 12 14 10 10 10 10 0 0 0 0
04/13 2 0 0 0 0 0 0 0 0 0
Press: (N)ext Page, (P)revious Page, C(l)ear History
------------------------------------------------------------------------------
Press to cycle through Interface : H2TU-R DS-1
choices and to view Statistics : 31 Day History
ID: xxxx--xxxx--xxxx--xxxx 04/15/00 12:30:01 H2TU-C System: OK
