ADC H2TU-C-388 - Manual (Page 24)

Provisioning 152-388-100-02, Issue 2
16 June 6, 2000 H2TU-C-388 List 1
Figure 7. Configuration Menu - Standard Options (Defaults Shown)
Figure 8. Configuration Menu - ADC Options (Defaults Shown)
Monitor Performance Event Log Config Inventory Rlogon Help
+----------------------+
|
Standard Options -> |
+---------------------------------------------------+
| Loopback Timeout (LBTO)
: 60 min |
| Loop Attenuation Threshold (LATT) [0-40]: 35 dB |
| Margin Threshold (MARG) [0-15]: 4 dB |
| DS1 Frame Formatting (FRMG) : AUTO |
| DS1 Line coding (DS1) : AUTO |
| H2TU-C Equalization (EQL) : 0 ft |
| H2TU-R Line Buildout (RLBO) : 0 dB |
| Alarm Pattern (ALMP) : AIS |
| H2TU-R TLOS Loopback (TLOS) : DIS |
| Network Loopback Pattern (NLBP) : AIS |
+---------------------------------------------------+
Press to cycle through settings and to activate.
ID: xxxx--xxxx--xxxx--xxxx
04/15/00 12:30:01 H2TU-C System: OK
Monitor Performance Event Log Config Inventory Rlogon Help
+----------------------+
| Standard Options ->
|
| PairGain Options -> |
+-----------------------------------------------+
| Line Power Feed (PWRF)
: ON |
| Remote Provisioning (RTPV) : ENA |
| Bipolar Violation Transparency (BPVT) : DIS |
| DS1 BER (DBER) : DIS |
| | HDSL2 BER Threshold (HBER) : NONE |
| Special Loopback Mode (SPLB) : GNLB |
| SmartJack Loopback (LPBK) : ENA |
| Remote Disconnect Alarm (RDA) : ENA |
+-----------------------------------------------+
Press to cycle through settings and to activate.
ID: xxxx--xxxx--xxxx--xxxx
04/15/00 12:30:01 H2TU-C System: OK
