Local Terminal Configuration
Using the Main Menu
37
2. Select Interface Type and then type
Serial
.
3. Press 1, Port and then type the
Serial Port Number
. You see the
current serial port settings (Figure 2-9).
Modify/View Interface Values Menu - Firmware Rev
Interface Type
Serial
[1]Port
1.2 Serial
[2]Port Type
NA
[3]Serial port IP address
0.0.0.0
[4]Serial port subnet mask
255.255.252.192
[5]Serial port speed
9600
[6]Serial port mode
Direct
[7]Serial port hardware flow control
On
[8]Modem Init String
^s^M^d1^sATE0Q0V1X4
S0=1...
[9]Modem Hangup String
^d2^s+++^d2^sATH0^M^d2
[10]Modem Connect Responses
/CONNECT/300/CONNECT/1200/
...
[11]Modem No-Connect Responses
/NO CARRIER/BUSY/NO
DIALT...
S.Save changes and exit
0.Cancel changes and exit
Figure 2-9: Modify/View Serial Port Settings Menu
