Cables and Connectors
Serial Port Interface Cables
119
Serial Port Interface Cables
The following table shows the recommended cables for connecting the probe’s
serial port interface to a terminal or modem.
Cable Function
Cable Type
Connectors
Agilent Product
Number
Connect a terminal or
PC to the probe port for
configuring the probe.
RS-232 “Crossover”
or “null modem”
cable
25-pin male to 25-pin
male
25-pin male to 25-pin
female
9-pin female to 25-pin
male
13242G
13242H
24542G
Connect a modem to the
probe port for SLIP
communications.
“Straight-through”
RS-232 modem cable
25-pin male to 25-pin
male
25-pin male to 25-pin
female
13242M, 13242N, or
17355M
31391A
Table A-4: Serial Port Interface Cable
