APPLIED ENGINEERING RamKeeper - Manual (Page 21)

Connecting Cards to the Back of RamKeeper
To connect a card to the back of RamKeeper, you’ll simply
insert the cards edge connector into the Back Pocket’s slot
after you have inserted the RamKeeper into the Memory
Expansion Slot.
* Warning! Make sure all power is off before
continuing. Both LED’s should be off and. power
to the computer should still be off.
10.) Insert the RamKeeper into the Memory
Expansion Slot. Align the RamKeeper’s edge
connector with the Memory Expansion Slot then
use the heel of one hand to push the card down
into the slot and seat it firmly.
Insert RamKeeper into Memory Expansion Slot
Memory Expansion Slot
12 RamKeeper
RamKeeper
Back
Front
BackPocket
(rests outside
Memory Expansion Slot)
