87
LAN Information
IP Address LAN port IP address
IP Subnet Mask LAN port IP subnet mask
DHCP Server LAN port DHCP role - Enabled, Relay or disabled
WAN Information
Status “Not connected” or “Connected”
Virtual Circuit There are eight groups of PVC can be defined
VPI: The valid range for the VPI is 0 to 255
VCI: The valid range for the VCI is 32 to 65535
Connection Type Name of the WAN connection
IP Address
WAN port IP address
IP Subnet Mask WAN port IP subnet mask
Default Gateway The IP address of the default gateway
DNS
WAN port DHCP role - Enabled, Relay or disabled
NAT Enabled or disabled
ADSL
ADSL Firmware
Version
This is the DSL firmware version associated with your router
Line State This is the status of your ADSL link
Modulation This field displays the ADSL modulation status for G.dmt or
T1.413.
Annex mode To show the router’s type, e.g. Annex A, Annex B
SNR Margin To show the router’s SNR margin for Downstream/Upstream
Line Attenuation To show the router’s for Downstream/Upstream
Data Rate
To show the router’s data rate for Downstream/Upstream
12.2 System Log
Display system logs accumulated up to the present time. You can trace historical
information with this function.
