11
1.4 WebShare 111U Application
Follow the followings steps to cabling the device:
• Connect WAN Port to the telephone line throught RJ-11 cable (contained in
package).
• WebShare 111U can be connect in the following configuration:
¾
Directly to the PC, throught CAT5 cables (one is contained in
package) or USB cable (also provided with the device).
¾ To an Hub/Switch throught UPLINK Port thought CAT 5 cable
(contained in package).
• Connect AC-DC Adapter on AC and on device (POWER jack) in the reat r of
the product.
2. Using WebShare 111U
2.1 Cautions for using the WebShare 111U
• Do not place the 111U under high humidity and high temperature.
• Do not use the same power source for 111U with other equipment.
• Do not open or repair the case yourself.
• If the 111U is too hot, turn off the power immediately and have a
qualified serviceman repair it.
• Place the 111U on a stable surface.
• Only use the power adapter that comes with the package.
