Rule Index
Select 16 different rules, each rule’s detail can be set and saved.
Active
Select QoS is activated or deactivated.
Application
Select 11 different applications: IGMP, SIP, H.323, MGCP, SNMP,
DNS, DHCP, RIP, RSTP, RTCP, RTP.
Physical Port
Once you select the application, the associated ports will be
displayed.
Destination MAC Set the Ethernet MAC value that you want to filter in destination
side.
Destination IP
Set the IP address value that you want to filter in destination
side.
Destination Mask Set the subnet mask value that you want to filter in destination
side.
Destination Port
Range
Set the port range value that you want to filter in destination
side.
Source MAC
Set the Ethernet MAC value that you want to filter in source
side.
Source IP
Set the IP address value that you want to filter in source side.
Source Mask
Set the subnet mask value that you want to filter in source side.
Source Port Range Set the port range value that you want to filter in source side.
Protocol ID
Set the protocol ID type that you want to filter.
VLan ID Range
Set the Vlan value that you want to filter.
IPP/DS Field
Select IP QoS format.
IP Precedence
Range
Select the IP precedence range.
Type of Service
Select 5 different type of service.
DSCP Range
Set the DSCP value that you want to filter.
802.1p
Set the remarked new 802.1p priority value on the packet that
fulfill every detail setting condition of each rule.
ACTION
IPP/DS Field
Select IP QoS format.
IP Precedente
Remarking
Select the remarking value of IP precedence.
Type of Service
Remarking
Select the remarking value of type of service.
