69
Both the user’s Operating System and the relevant application must support UPnP in
addition to the router. Windows XP and Windows Me natively support UPnP (when the
component is installed), and Windows 98 users may install the Internet Connection
Sharing client from Windows XP in order to support UPnP. Windows 2000 does not
support UPnP.
Field Description
UPnP Select this checkbox to activate UPnP. Be aware that anyone
could use a UPnP application to open the web configurator's
login screen without entering the WEBSHARE 111U IP
address
Auto-configured Select this check box to allow UPnP-enabled applications to
automatically configure the WEBSHARE 111U so that they can
communicate through the WEBSHARE 111U, for example by
using NAT traversal, UPnP applications automatically reserve
a NAT forwarding port in order to communicate with another
UPnP enabled device; this eliminates the need to manually
configure port forwarding for the UPnP enabled application
