48
Service Name (PPPoE only) Type the name of your PPPoE service here.
User Name
Enter the user name exactly as your ISP assigned. If assigned a
name in the form user@domain where domain identifies a service
name, then enter both components exactly as given.
Password
A static IP address is a fixed IP that your ISP gives you. A dynamic
IP address is not fixed; the ISP assigns you a different one each
time you connect to the Internet. The Single User Account feature
can be used with either a dynamic or static IP address.
Select Obtain an IP Address Automatically if you have a dynamic IP
address; otherwise select Static IP Address and type your ISP
assigned IP address in the IP Address field below.
Multiplex
Select the method of multiplexing used by your ISP from the drop-
down list. Choices are VC or LLC.
Connection Settings
Always ON
Select Always ON Connection when you want your connection up
all the time. The ADSL Router will try to bring up the connection
automatically if it is disconnected.
Connect on
Demand
Connect on demand is dependent on the traffic. If there is no
traffic (or Idle) for a pre-specified period of time), the connenct will
tear down automatically. And once there is traffic send or receive,
the connection will be automatically on. Please insert the Idle Time
in minute.
IP Address
Get IP Address
The IP address can be either dynamically (via DHCP) or given IP
address provide by your ISP. For Static IP, you need to specify the
IP address, Subnet Mask and Gateway IP address.
IP Address You must specify a Router IP address.
IP Subnet Mask
Enter a subnet mask in dotted decimal notation.
Refer to the Subnetting appendix in the to calculate a subnet mask
If you are implementing subnetting.
Gateway You must specify a gateway IP address.
NAT Select this option to Activate/Deactivated the NAT (Network
