65
Field Description
IP Filter set Editing
IP Filter set Index This is item number
Interface Select which channel (PVC) to configure
Direction Select the access to the Internet (“Outgoing”) or from the
Internet (“Incoming”) or Both
IP Filter Rule Editing
IP Filter Rule Index This is item number
Rule Type
Select Yes from the drop down list box to enable IP filter rule
Active The source IP address or range of packets to be monitored
Source IP Address It is the destination IP addresses based on above destination
subnet IP
Subnet Mask
(Source)
This Port or Port Ranges defines the port allowed to be used
by the Remote/WAN to connect to the application. Default is
set from range 0 ~ 65535. It is recommended that this option
be configured by an advanced user
Port Number (Surce) This is the destination subnet IP address
Destination IP
Address
It is the destination IP addresses based on above destination
subnet IP
Subnet
Mask(destination)
It is the packet protocol type used by the application, select
either TCP or UDP or ICMP
Port
Number(destination)
Select action for the traffic unmatching current rule; Forward
to leave it pass through, and NEXT to check it by the next
rule
Protocol This is item number
Rule Unmatched Select Yes from the drop down list box to enable IP filter rule
IP Filter Listing
# Item number
Active Whether the connection is currently activ
Source IP Mask The source IP address or range of packets to be monitored
Destination IP Mask This is the destination subnet IP address
Source port
This Port or Port Ranges defines the port allowed to be used
by the Remote/WAN to connect to the application. Default is
set from range 0 ~ 65535. It is recommended that this option
