80
DSCP Marking Select the remarking value of DSCP.
802.1p Marking Select the remarking value of 802.1p.
Queue# Select four types of Queue: Low, Medium, High, Highest.
10.6 ADSL
Field Description
ADSL Mode The default setting is Auto Sync-UP. This mode will
automatically detect your ADSL, ADSL2+, ADSL2, G.dmt, G.lite,
and T1.413. But in some area, multimode cannot detect the
ADSL line code well. If it is the case, please adjust the ADSL
line code to G.dmt or T1.413 first. If it still fails, please try the
other values such as ALCTL, ADI, etc
ADSL Type There are five modes “Open Annex Type and Follow DSLAM’s
Setting”, ”Annex A”, ”Annex I”, “Annex A/L”, ”Annex M” and
“Annex A/I/L/M” that user can select for this connection
10.7 Firewall
In this section You can set Firewall and SPI protection on WebShare 111U.
