Configuration with utility – Atlantis Land 111U User Manual
Page 22
22
It i s possibile to continue to follow step. If it show you follow message:
Pinging 192.168.1.254 with 32 bytes of data:
Request timed out.
Request timed out.
Request timed out.
Check that LAN LED is lit (change CAT cable if is not). Check PC IP Address typing
winipcfg for (Win95,98,ME) or ipconfig (for Win2000,XP) and eventually re-install
TCP/IP stack.
3.4 Browser Configuration
Now open IE, go to Instruments menu, select the Connections tab and select one
of the following options:
•
Never use remote connection
•
Use remote connection if another network connection isn’t available
4. Configuration with utility
4.1 WebShare Configuration Utility
WebShare 111U has provided with an easy installation utility in order to make
installation more easy and simple.
To start the configuration utility, please follow these instructions:
1.
Insert the CD-ROM and the Auto-run program will appear. Altenatively, you
may need to proceed the software manually; go to your Windows Start
menu and choose Run, type “
RA111U\Utility\UTILITY.EXE” in dialog box and click OK.
D:\ will depends on where the CD-ROM drive is located and
