4-28 Chapter 4: BIOS setup
4.4.5 SLI Configuration
AI-Selector[Auto]
Allows you to select the Scalable Link Interface mode. When set to [Auto], BIOS
detects the setting of SLI EZ Selector Card. Set this item to [Single Video Card]
when using single PCI-E graphics card.
Configuration: [Auto] [Single Video Card] [Dual Video Card]
F1:Help ↑↓ : Select Item -/+: Change Value F5: Setup Defaults
ESC: Exit →←: Select Menu Enter: Select Sub-menu F10: Save and Exit
Phoenix-AwardBIOS CMOS Setup Utility
Advanced
Select Menu
Item Specific Help
Allow you to select
the Scalable Link
Interface mode. When
set to Auto, BIOS
detects the setting of
SLI EZ Selector Card.
Set to Normal when
using single PCI-E
graphics card plugged.
SLI Configuration
AI-Selector [Auto]
Onboard 1394 [Enabled]
Enable or Disable Onboard 1394.
Configuration options: [Enabled] [Disabled]
Serial Port1 Address [3F8/IRQ4]
Allows you to select the Serial Port1 base address.
Configuration options: [Disabled] [3F8/IRQ4] [2F8/IRQ3] [3E8/IRQ4] [2E8/IRQ3]
[Auto]
Parallel Port Address [378/IRQ7]
Allows you to select the Parallel Port base addresses.
Configuration options: [Disabled] [378/IRQ7] [278/IRQ5] [3BC/IRQ7]
Parallel Port Mode [EPP]
Allows you to select the Parallel Port mode.
Configuration options: [Normal] [EPP] [ECP] [Bi-Directional]
The ECP Mode Use DMA item becomes user-configurable when the Parallel
Port Mode item is set to [ECP] or [Bi-Directional]
ECP Mode Use DMA [3]
Allows selection of ECP Mode. Configuration options: [1] [3]
