ASUS M2N-Plus SLI Vista Edition 2-23
Refer to the audio configuration table below for the function of the audio ports in
2, 4, 6, or 8-channel configuration.
9. Microphone port (pink). This port connects a microphone.
10. Center/Subwoofer port (orange). This port connects the center/subwoofer
speakers.
Audio 2, 4, 6, or 8-channel configuration
11. USB 2.0 ports 1 and 2, 3 and 4. These 4-pin Universal Serial Bus (USB)
ports are available for connecting USB 2.0 devices.
Connect the IR receiver ONLY to USB port 1 and 2, which support remote
control function. Plugging any other USB devices to these two ports will turn on
the computer.
12. Serial port (COM port). This 9-pin COM port is for pointing devices and
other serial devices.
13. Coaxial S/PDIF Out port. This port connects an external audio output device
via a coaxial S/PDIF cable.
14. PS/2 keyboard port (purple). This port is for a PS/2 keyboard.
Port
Headset
2-channel 4-channel
6-channel 8-channel
Light Blue Line In Line In Line In Line In
Lime Line Out Front Speaker Out Front Speaker Out Front Speaker Out
Pink Mic In Mic In Mic In Mic In
Orange – – Center/Subwoofer Center/Subwoofer
Black – – – Rear Speaker Out
Gray – Side Speaker Out Side Speaker Out Side Speaker Out
