Asus VISTA EDITION M2N-PLUS SLI User Manual
Page 54
2-30
Chapter 2: Hardware information
12. TPM connector (20-1 pin TPM)
This connector supports a Trusted Platform Module (TPM) system, which can
securely store keys, digital certificates, passwords, and data. A TPM system
also helps enhance network security, protects digital identities, and ensures
platform integrity. See section “4.6.6 Security” for details.
M2N-PLUS SLI
®
M2N-PLUS SLI TPM connector
TPM
M2N-PLUS SLI
®
M2N-PLUS SLI Digital audio connector
+5V
SPDIFOUT
GND
SPDIF_OUT
11. Digital audio connector (4-1 pin SPDIF_OUT)
This connector is for an additional Sony/Philips Digital Interface (S/PDIF)
port(s). Connect the S/PDIF Out module cable to this connector, then install
the module to a slot opening at the back of the system chassis.
The S/PDIF module is purchased separately.
The TPM module is purchased separately. Use the ASUS TPM module ONLY.
