ASUS M2N-Plus SLI Vista Edition 2-5
Internal connectors Page
1. Floppy disk drive connector (34-1 pin FLOPPY) 2-24
2. IDE connector (40-1 pin PRI_IDE, SEC_IDE) 2-24
3. NVIDIA ® nForce ® 500 SLI Southbridge Serial ATA connectors
(7-pin SATA1 [red], SATA2 [red], SATA3 [red], SATA4 [red])
2-25
4. CPU, chassis, and power fan connectors
(4-pin CPU_FAN, 3-pin PWR_FAN, 3-pin CHA_FAN )
2-26
5. USB connectors (10-1 pin USB56, USB78, ASAP) 2-27
6. IEEE 1394a port connector (10-1 pin IE1394_2) 2-27
7. Chassis intrusion connector (4-1 pin CHASSIS) 2-28
8. ATX power connectors (24-pin EATXPWR, 4-pin ATX12V) 2-28
9. Front panel audio connector (10-1 pin FP_AUDIO) 2-29
10. Internal audio connector (4-pin CD) 2-29
11. Digital audio connector (4-1 pin SPDIF_OUT) 2-30
12. TPM connector (20-1 pin TPM) 2-30
13. System panel connector (20-8-pin PANEL)
• System power LED (2-pin PLED)
• Hard disk drive activity LED (2-pin IDE_LED)
• System warning speaker (4-pin SPEAKER)
• ATX power button/soft-off button (2-pin PWRSW)
• Reset button (2-pin RESET)
2-31
