2-4 Chapter 2: Hardware information
2.2.4 Layout contents
Slots Page
1. DDR2 DIMM slots 2-11
2. PCI slots 2-18
3. PCI Express x 1 slot 2-18
4. PCI Express x16 slots 2-19
Jumper Page
1. Clear RTC RAM (3-pin CLRTC) 2-20
2. USB device wake-up (3-pin USBPW12, USBPW34, USBPW56,
USBPW78)
2-21
3. Keyboard power (3-pin KBPWR) 2-21
Rear panel connectors Page
1. PS/2 mouse port (green) 2-22
2. Parallel port 2-22
3. IEEE 1394a port 2-22
4. LAN (RJ-45) port. 2-22
5. Rear Speaker Out port (black) 2-22
6. Side Speaker Out port (gray) 2-22
7. Line In port (light blue) 2-22
8. Line Out port (lime) 2-22
9. Microphone port (pink) 2-23
10. Center/Subwoofer port (orange) 2-23
11. USB 2.0 ports 1 and 2, 3 and 4 2-23
12. Serial port (COM port) 2-23
13. Coaxial S/PDIF Out port 2-23
14 PS/2 keyboard port (purple) 2-23
