HDD AUDIO PLAYER
HAP-S1
Design and specifications
AUDIO POWER SPECIFICATIONS
POWER OUTPUT AND TOTAL HARMONIC DISTORTION (for the USA and Canada only):
With 4 ohm loads, both channels driven, from 20 - 20,000 Hz; rated 32 watts per channel minimum RMS
power, with no more than 10% total harmonic distortion from 250 milliwatts to rated output.
Amplifier section
POWER OUTPUT: 40 W + 40 W (4 ohms, 1 kHz, THD 10%)
Rated Power Output: 35 W + 35 W (4 ohms, 1 kHz, THD 0.9%)
Speaker impedance match: 4 ohms - 16 ohms
S/N ratio: 100 dB (20 kHz LPF, A Network)
Frequency response: 10 Hz - 100 kHz (+0 dB, –3 dB) (4 ohms, LINE IN)
Network section
Wired LAN
1000BASE-T/100BASE-TX/10BASE-T
Wireless LAN
Compatible standards: IEEE 802.11 b/g/n
Frequency band/channel: 2.4 GHz band, channels 1-11 (models for the USA and Canada), channels 1-13
(models for Europe)
HDD section
Capacity
500 GB (*)
*
Some portions of the capacity are used for data management. Therefore, the capacity a user can use is less
than 500 GB.
Supported playback format
DSD (DSF, DSDIFF), LPCM (WAV, AIFF), FLAC, ALAC, ATRAC Advanced Lossless, ATRAC, MP3, AAC, WMA
(2 channels)
Jack section
Input section
