Wiring distance

Power supply

Diameter

Distance

A

-

0.65 mm (22 AWG)

50m (165')

-

1.0 mm (18 AWG)

100m (330')

B

12 - 18V AC or DC

or less

0.65 - 1.0 mm

(22 - 18 AWG)

100m (330')

18 - 24V AC or DC

0.65 - 1.0 mm

(22 - 18 AWG)

300m (980')

C

-

0.65 - 1.0 mm

(22 - 18 AWG)

300m (980')

D

-

The connection distance will depend on

the specifications of the electric door strike,

relays or electromagnetic door lock to be

connected. To determine the operating

range, please refer to the specifications of

each terminal.

N/C contact

Power supply

User group1 relay 1

User group2 relay 2

Request to

exit/entry

button 1

Request to

exit/entry

button 2

N/C contact

N/O contact

N/O contact

Power supply
Between 12 and 24V AC

Between 12 and 24V DC

Request to exit/entry button, Timer

Minimum overload : 100mV DC, 0.1mA or above

Contact capacity : 3V DC, 0.1A or above

Relay
24V DC, 3A (resistive load) 1A (inductive load)

24V AC, 3A (resistive load) 1A (inductive load)

Minimum overload : 5V DC, 100mA or above

V

V

A1

A2

PB1

PB2

C

T

NO1

C1

NC1

NO2

C2

NC2

Timer

Common

JK-1MD

JK-1MED

A

B

2

2

2

2

2

2

2

2

C

D

A1 A2

A1
A2

L
L

Master station

Video door station

Video

door

station

Access control keypad

Access

control

keypad

Power supply

Request to exit/entry button

Timer

Relay

Relay

Automatic gate

Electromagnetic
door lock

Electric door strike

or

Request to exit/entry button

or

or

WIRING AND CONNECTIONS

Outline of connections and wiring distance

Terminal names

(Terminals for Video door station)

(Terminals for Access control keypad)
