3
English
Français
Nederlands
Door station with Flush mount back box Special screwdriver
Transparent
nameplate (x2)
Installation & Operation manual
"Do not install this unit in any of the following locations where lighting or the ambient environment could impact the display on
the video monitor due to the characteristics of the door station's camera."
a
Locations subject to
direct sunlight
b
Under street lights or door
lights
c
Other locations subject to strong
lighting or backlighting conditions
Wide picture
Zoom picture
The zoom position can be changed.
(Refer to the master station's operation manual.)
The factory setting is "Center" for Zoom mode.
Approx.
1,050 mm
(3' 5")
Approx. 700 mm (2' 3")
Approx. 900 mm (3')
Objects appear smaller
due to greater distortion in
the surrounding sections
compared to the central
section, but a wider area is
displayed.
The display range is a
rough estimation and
may change due to the
installation environment.
Up/Down Mounting position
1,500 mm (5')
Left/Right
Approx. 1,050 mm (3' 5")
Approx. 2,050 mm
(6' 9")
Approx. 1,000 mm
(3' 4")
500 mm (20")
1,500 mm (5')
Unit center
Approx. 1,850 mm
(6' 2")
Approx. 1,050 mm (3' 5")
Approx. 800 mm
(2' 7")
Mounting position
1,300 mm (4' 3")
Unit center
1,300 mm (4' 3")
500 mm (20")
Approx. 170°
Left/Right
Up/Down
500 mm (20")
Zoom
Approx. 850 mm (2' 9")
Approx. 1,450 mm
(4' 9")
500 mm
(20")
Unit center
1,500 mm (5')
Approx. 700 mm
(2' 3")
Approx. 1,200 mm
(3' 11")
Zoom Zoom
Approx. 1,650 mm
(5' 6")
Approx. 850 mm
(2' 9")
500 mm (20")
Unit center
1,500 mm (5')
Zoom Zoom Zoom
500 mm (20")
500 mm
(20")
Approx.
100 mm (4")
Approx.
1,300 mm (4' 3") Approx. 900 mm (3')
Approx.
1,300 mm (4' 3")
Approx. 100 mm
(4")
Unit center
1,500 mm (5')
500 mm
(20")
Wide picture
Zoom picture (when mounting position is 1,500 mm (5'))
500 mm (20")
An area over a range of approx. 170° in a 500 mm
(20") radius from the camera displays.
(The display range is a rough estimation and may
change due to the installation environment.)
Approx. 2,300 mm
(7' 7") Approx. 1,900 mm
(6' 4")
Approx. 800 mm
(2' 7")
PACKAGE CONTENTS
MOUNTING
Mounting locations
Mounting positions and image view area of Video door station
