SET UP
FUNCTION
FIRST BUTTON SEQUENCE
SECOND BUTTON SEQUENCE
NOTES
1. Turn the controller on
Turn switch on. The switch is
Also at this time, ***please
located on the rear panel.
TURN ON SOLO ****and
make sure the Grand Master fader
is up and DBO is off
2. Set up Fixtures
ADD FIXTURE ENTER
If a fixture number other than 1 appears
on the screen, this is the next available
"open" fixture number. To empty
memory
see
DELETE
.
3. Choose Fixture Type
Use ^ or v keys
to move cursor to
Use YES or NO keys to select
[type:" "]
the fixture
4. Add the fixture to the show
Press F1
This brings up a screen called the
EDIT
FIXTURE
MENU.
5. Naming the fixture.
Use ^ or v keys to move cursor to
Use keyboard to type in your
[Name:" "]
personal name. (stage left light 1).
6. Selecting the DMX port.
Use ^ or v
keys to move cursor to
Use YES ot NO keys to
You’ve got 2 x 5 pin XLRs on the
[DMX Port:" "]
select port 1 or 2.
back of the CP-100 marked out 1
and out 2. These are your DMX ports.
7. To change DMX channel
Use > key to change from
Use the number buttons and then
The controller will automatically
address
[DMX Port" "] to
press ENTER .
default
to the next unused DMX
[Base Channel:" "].
channel address, called the
"Base Channel" (or start channel).
8. To Change Dimmer Port
Use > key to change from Base
Use the YES or NO keys to
Having access to changing the dimmer
channel to dimmer port
change between ports 1 or 2
port is only available if the fixture
supports a DMX changeable dimmer.
For
example,
Vari*lite
VL5.
9. To Change Dimmer Channel
Use > key to change from dimmer
Use the number buttons and then
Like the dimmer port, access to this
port to dimmer channel
press ENTER
is only available if the fixture
supports a DMX changeable dimmer.
10.To Change default settings
Use > key to change from
Use > to change from
Unless you need to switch/invert the
for Pan and/or Tilt
[Base Channel:" "] to Pan
Pan to Tilt and then onto
Pan or Tilt functions these need not
Pan/Tilt invert.
be changed.
