2
VERTICAL CONTACT TOASTER
P/N 1010719 Rev. E 02/13
General
The Vertical Contact Toaster Model VCT-20 is designed
for contact toasting of buns. The toaster design allows
the operator to place buns on both sides of the heated
platen at the same time. Buns are placed into the top
of the toaster and uniform, golden brown, warm buns
are then retrieved at the base of the toaster.
This manual provides the safety, installation and oper-
ating procedures for the Vertical Contact Toaster Model
VCT-20. We recommend that all information contained
in this manual be read prior to installing and operating
the unit.
Your Vertical Contact Toaster Model VCT-20 is manu-
factured from the finest materials available and is
assembled to Roundup’s strict quality standards. This
unit has been tested at the factory to ensure depend-
able trouble-free operation.
OWNER INFORMATION
TABLE OF CONTENTS
IMPORTANT! Keep these instructions for future reference. If the unit changes owner-
ship, be sure this manual accompanies the equipment.
Warranty Information
Please read the full text of the Limited Warranty in this
manual.
If the unit arrives damaged, contact the carrier immedi-
ately and file a damage claim with them. Save all
packing materials when filing a claim. Freight damage
claims are the responsibility of the purchaser and are
not covered under warranty.
The warranty
does not extend to:
• Damages caused in shipment or damage as
result of improper use.
• Installation of electrical service.
• Normal maintenance as outlined in this manual.
• Malfunction resulting from improper maintenance.
• Damage caused by abuse or careless handling.
• Damage from moisture into electrical
components
• Damage from tampering with, removal of, or
changing any preset control or safety device.
Owner Information .....................................................2
General ......................................................................2
Warranty Information .................................................2
Service/Technical Assistance ....................................3
Important .....................................................................3
Important Safety Information ....................................4
Specifications .............................................................5
Electrical Specifications at Listed Voltages ...............5
Electrical Cord & Plug Configurations .......................5
Model Designation .....................................................5
Dimensions ................................................................6
Installation ...................................................................7
Unpacking ..................................................................7
Assembling the Unit ..................................................7
Equipment Setup .......................................................8
Operation .....................................................................9
Operating Instructions ...............................................9
Temperature Adjustments ..........................................9
Hi-Limit Reset Button ..............................................11
Fault Codes .............................................................12
Maintenance ..............................................................13
Maintenance Schedule ............................................13
Cleaning the Release Sheet and BeltWraps ...........13
Replacing Belt Wraps ..............................................14
Stainless Steel Conveyor Belts–Removing, Servicing
& Replacing .............................................................15
Replacing Roller Tensioners ....................................15
Replacing Conveyor Motor and Fan Blade .............15
Troubleshooting .......................................................17
Wiring Diagrams .......................................................25
Pictorial Wiring Diagram ..........................................25
Ladder Wiring Diagram ...........................................26
Replacement Parts ...................................................27
Parts Identification ...................................................27
Notes..........................................................................34
Limited Warranty ......................................................36
