5 SPEKTRUM DX3R PRO USER GUIDE
IdENTIfyINg buTTONs, swITChEs aNd CONTrOls
1
2
3
4
14
13
5
6
7
9
15
17
10
11
12
8
WARNING: ENSURE FUTURE ANTENNA SAFETY
Do not attempt to use the antenna to bear any weight, pick up
the transmitter by the antenna or alter the antenna in any way.
If the transmitter antenna or related components become
damaged the output strength can be severely impeded which
will likely lead to a crash, injury, and property damage.
16
1: Antenna 2: Backlit LCD Screen 3: Switch D/Steering Rate
4: Switch E/Brake 5: Button F/Rolling Lap Timer 6: Charge Jack
7: Switch A/Throttle Trim 8: Switch B/Steering Trim 9: Switch C/Aux 3 Linear
10: Rolling Selector 11: Battery Door 12: On/Off Switch
13: Throttle Trigger 14: Steering Wheel 15: Steering Tension Adjustment
16: SD Card Reader (under grip) 17: Steering Wheel Dropdown
(not available on all transmitters)
