11 SPEKTRUM DX3R PRO USER GUIDE
EN
TImEr
The DX3R PRO offers four types of timers:
Int- Internal
Dn Tmr- Down Timer
Up Tmr- Up Timer
Lap- Rolling Lap Timer
Timer A or B can be assigned to one of the four types. Both
timers will be shown on the Main screen.
Internal Timer (Default Timer A)
Automatically records the time the transmitter is turned
on. To reset the internal timer, rotate the roller to highlight
Internal Reset and then press the roller.
Rolling Lap Timer (Default Timer B)
Is programmable from 0:00.5 to 4:59.9 minutes in .1
second increments. The Rolling Lap timer is started via a
selectable programmable switch. When the timer expires,
an alarm sounds and the Lap timer resets and begins to
count down again. To pause the timer, press the button/
switch the timer is programmed to. To reset the timer to
its preprogrammed value, press and hold the programmed
button for more than three seconds. Button F defaults to
the timer.
Up Timer
The Up Timer is triggered via a selectable button/switch.
It counts up from 00:00 seconds, functioning as a
stopwatch. It is useful for timing a fuel run to determine
fuel mileage/pit stop strategy or, for electrics, to time
the run time of a pack to determine gear ratio and setup
information. To pause the Up timer, press the button/
switch the timer is programmed to. To reset the UP timer
to 00:00, press and hold the programmed button for
more than three seconds.
Down Timer
Is programmable for up to 99 minutes and 99 seconds
in one-second increments. The Down timer is started
via a selectable button/switch. When the down timer
expires, an alarm sounds and the timer begins to count
up. To pause the Down timer, press the button/switch the
timer is programmed to. To reset the Down timer to its
preprogrammed value, press and hold the programmed
button for more than three seconds.
Note: If Down timer is selected, press the roller
again to change the time. Rotate the roller to
change the time.
• From the List screen rotate the roller to highlight the
Timer function.
• Press the roller to enter the Timer
function. The Timer screen will
display as shown below.
• Rotate the roller to highlight the
desired Timer you choose to
program (Timer A or Timer B).
• Press the roller to enter the
highlighted Timer function.
• Rotate the roller to select the
desired type within Timer A or
Timer B:
Int- Internal
Dn Tmr- Down Timer
Up Tmr- Up Timer
Lap- Rolling Lap Timer
See System on page 15, 16 for details on programming
the timers to various buttons and switches.
bINdINg
In order to operate you must bind the receiver to
the transmitter. Binding is teaching the receiver to
recognize the transmitter’s specific GUID code.
The DX3R Pro employs ModelMatch so the receiver
stores the code assigned to the currently selected
model in the transmitter. So when the receiver is
bound to a transmitter/model memory, the receiver
only responds to the stored transmitter/model
memory. This prevents operating a model using the
wrong model memory.
faIlsafE
Failsafe positions are also set during binding. In the
unlikely event that the radio link is lost during use, the
receiver will drive the servos to their preprogrammed
failsafe positions (normally full brakes and straight
steering). If the receiver is turned on prior to turning
on the transmitter, the receiver will enter failsafe mode,
driving the servos to their preset failsafe positions.
When the transmitter is turned on, normal control
is resumed. Failsafe servo positions are set during
binding (see binding a receiver below).
User Name
01: Model 01
Timer
Internal Reset
Int 0:08:19
Int 0:08:18
Timer A:
Lap 05:00
Timer B:
List
Travel
Steer Rate
Exponential
Reverse
Sub Trim
Timer
Bind
Frame Rate
Mixing
Servo Speed
