26 SPEKTRUM DX3R PRO USER GUIDE
EN
ChaNgINg TO lEfT-haNdEd
CONfIguraTION
The DX3R PRO comes set up for right-handed use, but
you can easily switch it to a left-handed configuration.
All the parts necessary to convert to left-handed,
including the grip plates, the back cover and the front
shell, are included. The included 3/32-inch hex wrench
and a small Phillips screwdriver will be needed.
1. Remove the batteries from the transmitter. This
prevents the possibility of accidentally causing
a short during the conversion.
2. Carefully remove the grip cover by prying with
your fingers at the forward edge of the rubber grip.
3. Using the 3/32-inch hex wrench, remove the three
screws on the front of the steering housing as shown.
4. Carefully remove the steering mechanism and
unplug the steering connector. Also remove the
backplate.
5. Using a small Phillips screwdriver, remove the four
Phillips screws (two per side) that fasten the grip
plates in place. Remove the grip plate that doesn’t
have the buttons attached.
6. Carefully pull out the grip plate that contains
buttons D, E and F. Using a Phillips screwdriver
remove the PC board and backplate from the grip
plate. Note the positions of the three buttons.
7. Transfer the three buttons (D, E and F) to the other
“handed” grip plate (included in the box). The buttons fit
in a specific direction so that they fit the external contour
of the grip plate.
